Partition Manager#

The partitioning module (par) is based on TritonPart, an open-source constraints-driven partitioner. par can be used to partition a hypergraph or a gate-level netlist.

Highlights#

  • Start of the art multiple-constraints driven partitioning “multi-tool”

  • Optimizes cost function based on user requirement

  • Permissive open-source license

  • Solves multi-way partitioning with following features:

    • Multidimensional real-value weights on vertices and hyperedges

    • Multilevel coarsening and refinement framework

    • Fixed vertices constraint

    • Timing-driven partitioning framework

    • Group constraint: Groups of vertices need to be in same block

    • Embedding-aware partitioning

Dependency#

We use Google OR-Tools as our ILP solver.

Our recommendation is to follow the OpenROAD DependencyInstaller for installation of this requirement.

Alternatively, you may also install Google OR-Tools following these instructions.

Warning

Due to a build issue, TritonPart is not supported for macOS. Stay tuned to this page for updates!

Main Algorithm#

An overview of the TritonPart algorithm is shown below. It takes as inputs

  • Hypergraph \(H(V,E)\) in .hgr format.

  • Vertex weight \(w_v \in \mathcal{R}_+^m\)

  • Hyperedge weight \(w_e \in \mathcal{R}_+^n\)

  • Number of blocks \(K\).

  • Imbalance factor \(\epsilon\).

  • User-specified cost function \(\phi\).

There are five main steps in the main algorithm, mainly 1) constraints-driven coarsening, 2) initial partitioning, 3) refinement, 4) cut-overlay clustering and partitioning (COCP), and 5) V-cycle refinement. The steps for the timing-aware algorithm may be found in the next section.

  1. Constraints-Driven Coarsening

The first step involves multilevel coarsening. Specifically, at each level, clusters of vertices are identified, and the merged and represented as a single vertex in the resulting coarser hypergraph. In this algorithm, the First-Choice scheme is used, which traverses the vertices in the hypergraph according to a given ordering and merges pairs of vertices with high connectivity. The connectivity between a pair of vertices \((u,v)\) is measured as follows:

\[r(u, v) = \sum_{e\in \{I(v)\cap I(u)\}} \frac{\langle \alpha, w_e\rangle}{|e|-1}\]

To efficiently manage multiple constraints, the following enhancements are made to the coarsening scheme above:

  • Fixed Vertex Constraint: Fixed vertices that belong to the same partitioning block are merged into a single vertex.

  • Grouping Constraint: Vertices that belong to the same group are merged into a single vertex.

  • Embedding Constraint: The embedding information is incorporated into the heavy-edge rating function. The new connectivity is updated as follows:

\[\hat{r}(u, v) = r(u, v) + \rho\frac{1}{||X_u - X_v||_2}\]

where \(\rho\) is a normalization factor set to the average distance between two vertex embeddings. When vertices \(v_1, ... , v_t\) are merged into a single vertex \(v_{coarse}\), the corresponding vertex embedding \(X_{v_{coarse}}\) is defined as the center of gravity of \(t\) vertices:

\[X_{v_{coarse}} = \sum_{j=1}^{t} \frac{||w_{v_j}||}{M} X_{v_j},\ where\ M= \sum_{j=1}^t ||w_{v_j}|| \]
  • Community Guidance: Only vertices within the same community are considered for merging.

  • Tie-breaking mechanism: If multiple neighbor pairs have the same rating score, combine the lexicographically first unmatched vertex to break ties.

  1. Initial Partitioning

After completing the coarsening process, an initial partitioning solution for the coarsest hypergraph \(H_c\) is derived. Two sub-steps are involved in this: the best partitioning solution from random and VILE partitioning is chosen from \(\eta = 50\) runs as a warm-start to the ILP-based partitioner. The optimization is based on only the cut size rather than the cost function \(\phi\) to keep the runtime reasonable.

  1. Refinement

After a feasible solution \(H_{c_\xi}\) is obtained by initial partitioning, uncoarsening and move-based refinement is performed to improve the partitioning solution. Three refinement heuristics are applied in sequence:

  • \(K\)-way pairwise FM (PM): This addresses multi-way partitioning as concurrent bi-partitioning problems in a restricted version of K-way Fiduccia–Mattheyses (FM) algorithm. First, \(\lfloor K/2\rfloor \) pairs of blocks are obtained, with refinement-specific vertex movements restricted to associated paired blocks. Next, two-way FM is concurrently performed on all the block pairs. finally, a new configuration of block pairs is computed at the end of the PM.

  • Direct \(K\)-way FM: Using \(K\) priority queues, for each block \(V_i\), establish a priority queue that stores the vertices that can be potentially moved from the current block to block \(V_i\). This queue is ordered according to the gain of the vertices. Gain is defined as the reduction in cost function from the movement of the vertex from the current block to \(V_i\). Next, after a vertex move, each priority queue is updated independently, thus enabling parallel updates via multi-threading. Next, early-stop is implemented by limiting the maximum number of vertices moved to 100 per pass. Finally, the corking effect is mitigated by traversing the priority queue belonging to the vertex with the highest gain and identifying a feasible vertex move.

  • Greedy Hyperedge Refinement (HER): First, randomly visit all hyperedges. For each hyperedge \(e\) that crosses the partition boundary, determine whether a subset of vertices in \(e\) can be moved without violating the multi-dimensional balance constraints. The objective is to make \(e\) entirely constrained in a block.

  1. Cut-Overlay Clustering and Partitioning (COCP)

Cut-overlay Clustering and Partitioning (COCP) is a mechanism to combine multiple good-quality partitioning solutions to generate an improved solution. To begin, the sets of hyperedges cut in the \(\theta\) candidate solutions are denoted as \(E_1,..., E_\theta \subset E\). First, \(\cup_{i=1}^\theta E_i\) is removed from the hypergraph \(H(V, E)\), resulting in a number of connected components. Next, all vertices within each connected component are merged to form a coarser hypergraph \(H_{overlay}\). If the number of vertices in \(H_{overlay}\) is less than \(thr_{ilp}\), ILP-based partitioning is performed. If not, a single round of constraints-driven coarsening is conducted to further reduce the size of \(H_{overlay}\) and generate a coarser hypergraph \(H_{overlay}^{'}\). Finally, multilevel refinement is performed to further improve the partitioning solution at each level of the hierarchy and return the improved solution \(S^{'}\).

  1. V-Cycle Refinement

Cut-overlay clustering and partitioning produces a high-quality partitioning solution \(S^{'}\). To improve it, there are three phases similar to hMETIS, namely multilevel coarsening, ILP-based partitioning, and refinement. Firstly, in multilevel partitioning, \(S^{'}\) is used as a community guidance for the constraints-driven coarsening. Only vertices within the same block are permitted to be merged to ensure that the current solution \(S^{'}\) is preserved in the coarsest hypergraph \(H_{c_\xi}\). In the ILP-based partitioning phase, if the number of vertices in \(H_{c_\xi}\) does not exceed \(thr_{ilp}\), run ILP-based partitioning to improve \(S^{'}\). Otherwise, continue with \(S^{'}\) in successive iterations of these two steps (default set to 2). The refinement phase is conducted as per step 3.

TritonPart algorithm at a glance

Timing Aware Algorithm#

par can also be used as a timing-aware partitioning framework. A slack propagation methodology is used that optimizes cuts for both timing-critical and timing-noncritical paths.

  1. Extraction of Timing Paths and Slack Information

First, the top \(P\) timing-critical paths and the slack information of each hyperedge using the wireload model (WLM) is obtained from OpenSTA. The timing cost of each path is then calculated:

\[t_p = (1- \frac{slack_p - \Delta}{clock\_period})^\mu\]

where a fixed extra delay \(\Delta\) is introduced for timing guardband, and \(\mu\) (default 2) is the exponent.

The snaking factor of a path \(SF(p)\) is defined as the maximum number of block reentries along the path \(p\). The timing cost of a hyperedge is computed using the timing weight corresponding to hyperedge slack \(slack_e\) and the accumulated timing cost of all paths traversing the hyperedge.

\[t_e = (1- \frac{slack_e -\Delta}{clock\_period})^\mu + \sum_{\{p|e\in p\}}t_p\]
  1. Timing-aware Coarsening

The timing-aware feature is achieved by adding a timing cost of hyperedge \(t_e\) to the connectivity score earlier mentioned. If vertices \((u,v)\) are associated with multiple critical paths, then they are more likely to be merged. This is reflected in the update score function:

\[r_t(u,v) = \hat{r}(u,v) + \sum_{e\in\{I(v) \cap I(u)\}} \frac{\beta t_e}{|e| - 1}\]
  1. Timing-aware Refinement

Timing-aware refinement is based on a similar cost function as the main algorithm. Instead, an additional slack propagation step is performed at the end of each PM/FM/HER pass.

Commands#

Note

  • Parameters in square brackets [-param param] are optional.

  • Parameters without square brackets -param2 param2 are required.

Partition Netlist#

triton_part_hypergraph
    -hypergraph_file hypergraph_file
    -num_parts num_parts
    -balance_constraint balance_constraint
    [-base_balance base_balance]
    [-seed seed]
    [-vertex_dimension vertex_dimension]
    [-hyperedge_dimension hyperedge_dimension]
    [-placement_dimension placement_dimension]
    [-fixed_file fixed_file]
    [-community_file community_file]
    [-group_file group_file]
    [-placement_file placement_file]
    [-e_wt_factors e_wt_factors]
    [-v_wt_factors <v_wt_factors>]
    [-placement_wt_factors <placement_wt_factors>]
    [-thr_coarsen_hyperedge_size_skip thr_coarsen_hyperedge_size_skip]
    [-thr_coarsen_vertices thr_coarsen_vertices]
    [-thr_coarsen_hyperedges thr_coarsen_hyperedges]
    [-coarsening_ratio coarsening_ratio]
    [-max_coarsen_iters max_coarsen_iters]
    [-adj_diff_ratio adj_diff_ratio]
    [-min_num_vertices_each_part min_num_vertices_each_part]
    [-num_initial_solutions num_initial_solutions]
    [-num_best_initial_solutions num_best_initial_solutions]
    [-refiner_iters refiner_iters]
    [-max_moves max_moves]
    [-early_stop_ratio early_stop_ratio]
    [-total_corking_passes total_corking_passes]
    [-v_cycle_flag v_cycle_flag ]
    [-max_num_vcycle max_num_vcycle]
    [-num_coarsen_solutions num_coarsen_solutions]
    [-num_vertices_threshold_ilp num_vertices_threshold_ilp]
    [-global_net_threshold global_net_threshold]

Options#

Switch Name

Description

-num_parts

Number of partitions. The default value is 2, and the allowed values are integers [0, MAX_INT].

-balance_constraint

Allowed imbalance between blocks. The default value is 1.0, and the allowed values are floats.

-base_balance

Tcl list of baseline imbalance between partitions. The default value is {1.0}, and the allowed values are floats that sum up to 1.0.

-seed

Random seed. The default value is 0, and the allowed values are integers [-MAX_INT, MAX_INT].

-vertex_dimension

Number of vertices in the hypergraph. The default value is 1, and the allowed values are integers [0, MAX_INT].

-hyperedge_dimension

Number of hyperedges in hypergraph. The default value is 1, and the allowed values are integers [0, MAX_INT].

-placement_dimension

Number of dimensions for canvas if placement information is provided. The default value is 0, and the allowed values are integers [0, MAX_INT].

-hypergraph_file

Path to hypergraph file.

-fixed_file

Path to fixed vertices constraint file.

-community_file

Path to community attributes file to guide the partitioning process.

-group_file

Path to stay together attributes file.

-placement_file

Placement information file, each line corresponds to a group fixed vertices, community, and placement attributes following the hMETIS format.

-e_wt_factors

Hyperedge weight factor.

-v_wt_factors

Vertex weight factors.

-placement_wt_factors

Placement weight factors.

-thr_coarsen_hyperedge_size_skip

Threshold for ignoring large hyperedge (default 200, integer).

-thr_coarsen_vertices

Number of vertices of coarsest hypergraph (default 10, integer).

-thr_coarsen_hyperedges

Number of vertices of coarsest hypergraph (default 50, integer).

-coarsening_ratio

Coarsening ratio of two adjacent hypergraphs (default 1.6, float).

-max_coarsen_iters

Number of iterations (default 30, integer).

-adj_diff_ratio

Minimum difference of two adjacent hypergraphs (default 0.0001, float).

-min_num_vertices_each_part

Minimum number of vertices in each partition (default 4, integer).

-num_initial_solutions

Number of initial solutions (default 50, integer).

-num_best_initial_solutions

Number of top initial solutions to filter out (default 10, integer).

-refiner_iters

Refinement iterations (default 10, integer).

-max_moves

The allowed moves for each Fiduccia-Mattheyes (FM) algorithm pass or greedy refinement (default 60, integer).

-early_stop_ratio

Describes the ratio \(e\) where if the \(n_{moved vertices} > n_{vertices} * e\), the tool exits the current FM pass. The intention behind this is that most of the gains are achieved by the first few FM moves. (default 0.5, float).

-total_corking_passes

Maximum level of traversing the buckets to solve the “corking effect” (default 25, integer).

-v_cycle_flag

Disables v-cycle is used to refine partitions (default true, bool).

-max_num_vcycle

Maximum number of vcycles (default 1, integer).

-num_coarsen_solutions

Number of coarsening solutions with different randoms seed (default 3, integer).

-num_vertices_threshold_ilp

Describes threshold \(t\), the number of vertices used for integer linear programming (ILP) partitioning. if \(n_{vertices} > t\), do not use ILP-based partitioning.(default 50, integer).

-global_net_threshold

If the net is larger than this, it will be ignored by TritonPart (default 1000, integer).

Evaluate Hypergraph Partition#

evaluate_hypergraph_solution
  -num_parts num_parts
  -balance_constraint balance_constraint
  -hypergraph_file hypergraph_file
  -solution_file solution_file
  [-base_balance base_balance]
  [-vertex_dimension vertex_dimension]
  [-hyperedge_dimension hyperedge_dimension]
  [-fixed_file fixed_file]
  [-group_file group_file]
  [-e_wt_factors e_wt_factors]
  [-v_wt_factors v_wt_factors]

Options#

Switch Name

Description

-num_parts

Number of partitions. The default value is 2, and the allowed values are integers [0, MAX_INT].

-balance_constraint

Allowed imbalance between blocks. The default value is 1.0, and the allowed values are floats.

-vertex_dimension

Number of vertices in the hypergraph. The default value is 1, and the allowed values are integers [0, MAX_INT].

-hyperedge_dimension

Number of hyperedges in hypergraph. The default value is 1, and the allowed values are integers [0, MAX_INT].

-hypergraph_file

Path to hypergraph file.

-solution_file

Path to solution file.

-base_balance

Tcl list of baseline imbalance between partitions. The default value is {1.0}, and the allowed values are floats that sum up to 1.0.

-fixed_file

Path to fixed vertices constraint file.

-group_file

Path to stay together attributes file.

-e_wt_factors

Hyperedge weight factor.

-v_wt_factors

Vertex weight factor.

Partition Netlist#

triton_part_design
    [-num_parts num_parts]
    [-balance_constraint balance_constraint]
    [-base_balance base_balance]
    [-seed seed]
    [-timing_aware_flag timing_aware_flag]
    [-top_n top_n]
    [-placement_flag placement_flag]
    [-fence_flag fence_flag]
    [-fence_lx fence_lx]
    [-fence_ly fence_ly]
    [-fence_ux fence_ux]
    [-fence_uy fence_uy]
    [-fixed_file fixed_file]
    [-community_file community_file]
    [-group_file group_file]
    [-solution_file solution_file]
    [-net_timing_factor net_timing_factor]
    [-path_timing_factor path_timing_factor]
    [-path_snaking_factor path_snaking_factor]
    [-timing_exp_factor timing_exp_factor]
    [-extra_delay extra_delay]
    [-guardband_flag guardband_flag]
    [-e_wt_factors e_wt_factors]
    [-v_wt_factors v_wt_factors]
    [-placement_wt_factors placement_wt_factors]
    [-thr_coarsen_hyperedge_size_skip thr_coarsen_hyperedge_size_skip]
    [-thr_coarsen_vertices thr_coarsen_vertices]
    [-thr_coarsen_hyperedges thr_coarsen_hyperedges]
    [-coarsening_ratio coarsening_ratio]
    [-max_coarsen_iters max_coarsen_iters]
    [-adj_diff_ratio adj_diff_ratio]
    [-min_num_vertices_each_part min_num_vertices_each_part]
    [-num_initial_solutions num_initial_solutions]
    [-num_best_initial_solutions num_best_initial_solutions]
    [-refiner_iters refiner_iters]
    [-max_moves max_moves]
    [-early_stop_ratio early_stop_ratio]
    [-total_corking_passes total_corking_passes]
    [-v_cycle_flag v_cycle_flag ]
    [-max_num_vcycle max_num_vcycle]
    [-num_coarsen_solutions num_coarsen_solutions]
    [-num_vertices_threshold_ilp num_vertices_threshold_ilp]
    [-global_net_threshold global_net_threshold]

Options#

Switch Name

Description

-num_parts

Number of partitions. The default value is 2, and the allowed values are integers [0, MAX_INT].

-balance_constraint

Allowed imbalance between blocks. The default value is 1.0, and the allowed values are floats.

-base_balance

Tcl list of baseline imbalance between partitions. The default value is {1.0}, and the allowed values are floats that sum up to 1.0.

-seed

Random seed. The default value is 1, and the allowed values are integers [-MAX_INT, MAX_INT].

-timing_aware_flag

Enable timing-driven mode. The default value is true, and the allowed values are booleans.

-top_n

Extract the top n critical timing paths. The default value is 1000, and the allowed values are integers [0, MAX_INT.

-placement_flag

Enable placement driven partitioning. The default value is false, and the allowed values are booleans.

-fence_flag

Consider fences in the partitioning. The default value is false, and the allowed values are booleans.

-fence_lx

Fence lower left x in microns. The default value is 0.0, and the allowed values are floats.

-fence_ly

Fence lower left y in microns. The default value is 0.0, and the allowed values are floats.

-fence_ux

Fence upper right x in microns. The default value is 0.0, and the allowed values are floats.

-fence_uy

Fence upper right y in microns. The default value is 0.0, and the allowed values are floats.

-fixed_file

Path to fixed vertices constraint file

-community_file

Path to community attributes file to guide the partitioning process.

-group_file

Path to stay together attributes file.

-solution_file

Path to solution file.

-net_timing_factor

Hyperedge timing weight factor (default 1.0, float).

-path_timing_factor

Cutting critical timing path weight factor (default 1.0, float).

-path_snaking_factor

Snaking a critical path weight factor (default 1.0, float).

-timing_exp_factor

Timing exponential factor for normalized slack (default 1.0, float).

-extra_delay

Extra delay introduced by a cut (default 1e-9, float).

-guardband_flag

Enable timing guardband option (default false, bool).

-e_wt_factors

Hyperedge weight factor.

-v_wt_factors

Vertex weight factor.

-placement_wt_factors

Placement weight factor.

-thr_coarsen_hyperedge_size_skip

Threshold for ignoring large hyperedge. The default value is 1000, and the allowed values are integers [0, MAX_INT].

-thr_coarsen_vertices

Number of vertices of coarsest hypergraph. The default value is 10, and the allowed values are integers [0, MAX_INT].

-thr_coarsen_hyperedges

Number of vertices of the coarsest hypergraph. The default value is 50, and the allowed values are integers [0, MAX_INT].

-coarsening_ratio

Coarsening ratio of two adjacent hypergraphs. The default value is 1.5, and the allowed values are floats.

-max_coarsen_iters

Number of iterations. The default value is 30, and the allowed values are integers [0, MAX_INT].

-adj_diff_ratio

Minimum ratio difference of two adjacent hypergraphs. The default value is 0.0001, and the allowed values are floats.

-min_num_vertices_each_part

Minimum number of vertices in each partition. The default value is 4, and the allowed values are integers [0, MAX_INT].

-num_initial_solutions

Number of initial solutions. The default value is 100, and the allowed values are integers [0, MAX_INT].

-num_best_initial_solutions

Number of top initial solutions to filter out. The default value is 10, and the allowed values are integers [0, MAX_INT].

-refiner_iters

Refinement iterations. The default value is 10, and the allowed values are integers [0, MAX_INT].

-max_moves

The allowed moves for each Fiduccia-Mattheyes (FM) algorithm pass or greedy refinement. The default value is 100, and the allowed values are integers [0, MAX_INT].

-early_stop_ratio

Describes the ratio \(e\) where if the \(n_{moved vertices} > n_{vertices} * e\), the tool exists the current FM pass. The intention behind this is that most of the gains are achieved by the first few FM moves. The default value is 0.5, and the allowed values are floats.

-total_corking_passes

Maximum level of traversing the buckets to solve the “corking effect”. The default value is 25, and the allowed values are integers [0, MAX_INT].

-v_cycle_flag

Disables v-cycle is used to refine partitions. The default value is true, and the allowed values are booleans.

-max_num_vcycle

Maximum number of vcycles. The default value is 1, and the allowed values are integers [0, MAX_INT].

-num_coarsen_solutions

Number of coarsening solutions with different randoms seed. The default value is 4, and the allowed values are integers [0, MAX_INT].

-num_vertices_threshold_ilp

Describes threshold \(t\), the number of vertices used for integer linear programming (ILP) partitioning. if \(n_{vertices} > t\), do not use ILP-based partitioning. The default value is 50, and the allowed values are integers [0, MAX_INT].

-global_net_threshold

If the net is larger than this, it will be ignored by TritonPart. The default value is 1000, and the allowed values are integers [0, MAX_INT].

Evaluation Netlist Partition#

evaluate_part_design_solution
    [-num_parts num_parts]
    [-balance_constraint balance_constraint]
    [-base_balance base_balance]
    [-timing_aware_flag timing_aware_flag]
    [-top_n top_n]
    [-fence_flag fence_flag]
    [-fence_lx fence_lx]
    [-fence_ly fence_ly]
    [-fence_ux fence_ux]
    [-fence_uy fence_uy]
    [-fixed_file fixed_file]
    [-community_file community_file]
    [-group_file group_file]
    [-hypergraph_file hypergraph_file]
    [-hypergraph_int_weight_file hypergraph_int_weight_file]
    [-solution_file solution_file]
    [-net_timing_factor net_timing_factor]
    [-path_timing_factor path_timing_factor]
    [-path_snaking_factor path_snaking_factor]
    [-timing_exp_factor timing_exp_factor]
    [-extra_delay extra_delay]
    [-guardband_flag guardband_flag]
    [-e_wt_factors e_wt_factors]
    [-v_wt_factors v_wt_factors]

Options#

Switch Name

Description

-num_parts

Number of partitions. The default value is 2, and the allowed values are integers [0, MAX_INT].

-balance_constraint

Allowed imbalance between blocks. The default value is 1.0, and the allowed values are floats.

-base_balance

Tcl list of baseline imbalance between partitions. The default value is {1.0}, and the allowed values are floats that sum up to 1.0.

-timing_aware_flag

Enable timing-driven mode. The default value is true, and the allowed values are booleans.

-top_n

Extract the top n critical timing paths. The default value is 1000, and the allowed values are integers [0, MAX_INT].

-fence_flag

Consider fences in the partitioning. The default value is false, and the allowed values are booleans.

-fence_lx

Fence lower left x in microns. The default value is 0.0, and the allowed values are floats.

-fence_ly

Fence lower left y in microns. The default value is 0.0, and the allowed values are floats.

-fence_ux

Fence upper right x in microns. The default value is 0.0, and the allowed values are floats.

-fence_uy

Fence upper right y in microns. The default value is 0.0, and the allowed values are floats.

-fixed_file

Path to fixed vertices constraint file.

-community_file

Path to community attributes file to guide the partitioning process.

-group_file

Path to stay together attributes file.

-hypergraph_file

Path to hypergraph file.

-hypergraph_int_weight_file

Path to hMETIS format integer weight file.

-solution_file

Path to solution file.

-net_timing_factor

Hyperedge timing weight factor. The default value is 1.0, and the allowed values are floats.

-path_timing_factor

Cutting critical timing path weight factor. The default value is 1.0, and the allowed values are floats.

-path_snaking_factor

Snaking a critical path weight factor. The default value is 1.0, and the allowed values are floats.

-timing_exp_factor

Timing exponential factor for normalized slack. The default value is 1.0, and the allowed values are floats.

-extra_delay

Extra delay introduced by a cut. The default value is 1e-9, and the allowed values are floats.

-guardband_flag

Enable timing guardband option. The default value is 1false, and the allowed values are booleans.

-e_wt_factors

Hyperedge weight factors.

-v_wt_factors

Vertex weight factors.

Write Partition to Verilog#

write_partition_verilog
    [-port_prefix prefix]
    [-module_suffix suffix]
    [file]

Options#

Switch Name

Description

-port_prefix

Port name prefix.

-module_suffix

Module name suffix.

file

Filename to write partition verilog to.

Read the Partition file#

read_partitioning
    -read_file name
    [-instance_map_file file_path]


## Example Scripts

### How to partition a hypergraph in the way you would using hMETIS (min-cut partitioning)

```tcl
triton_part_hypergraph -hypergraph_file des90.hgr -num_parts 5 -balance_constraint 2 -seed 2

You can also check the provided example here.

How to perform the embedding-aware partitioning#

set num_parts 2
set balance_constraint 2
set seed 0
set design sparcT1_chip2
set hypergraph_file "${design}.hgr"
set placement_file "${design}.hgr.ubfactor.2.numparts.2.embedding.dat"
set solution_file "${design}.hgr.part.${num_parts}"

triton_part_hypergraph  -hypergraph_file $hypergraph_file -num_parts $num_parts \
                        -balance_constraint $balance_constraint \
                        -seed $seed  \
                        -placement_file ${placement_file} -placement_wt_factors { 0.00005 0.00005 } \
                        -placement_dimension 2

You can find the provided example here.

How to partition a netlist#

# set technology information
set ALL_LEFS “list_of_lefs”
set ALL_LIBS “list_of_libs”
# set design information
set design “design_name”
set top_design “top_design”
set netlist “netlist.v”
set sdc “timing.sdc”
foreach lef_file ${ALL_LEFS} {
  read_lef $lef_file
}
foreach lib_file ${ALL_LIBS} {
  read_lib $lib_file
}
read_verilog $netlist
link_design $top_design
read_sdc $sdc

set num_parts 5
set balance_constraint 2
set seed 0
set top_n 100000
# set the extra_delay_cut to 20% of the clock period
# the extra_delay_cut is introduced for each cut hyperedge
set extra_delay_cut 9.2e-10
set timing_aware_flag true
set timing_guardband true
set part_design_solution_file "${design}_part_design.hgr.part.${num_parts}"

##############################################################################################
### TritonPart with slack progagation
##############################################################################################
puts "Start TritonPart with slack propagation"
# call triton_part to partition the netlist
triton_part_design -num_parts $num_parts -balance_constraint $balance_constraint \
                   -seed $seed -top_n $top_n \
                   -timing_aware_flag $timing_aware_flag -extra_delay $extra_delay_cut \
                   -guardband_flag $timing_guardband \
                   -solution_file $part_design_solution_file

You can find the provided example here.

Regression tests#

There are a set of regression tests in ./test. For more information, refer to this section.

Simply run the following script:

./test/regression

References#

  1. Bustany, I., Kahng, A. B., Koutis, I., Pramanik, B., & Wang, Z. (2023). K-SpecPart: A Supervised Spectral Framework for Multi-Way Hypergraph Partitioning Solution Improvement. arXiv preprint arXiv:2305.06167. (.pdf)

  2. Bustany, I., Gasparyan, G., Kahng, A. B., Koutis, I., Pramanik, B., & Wang, Z. (2023). “An Open-Source Constraints-Driven General Partitioning Multi-Tool for VLSI Physical Design”, Proc. ACM/IEEE International Conference of Computer-Aided Design 2023,(.pdf).

License#

BSD 3-Clause License. See LICENSE file.
